M_Super_aln_boot_phylo_New

None

/* Accepts sequences in FASTA format and extracts the information from them for a better understanding of the multiple sequence alignment and trees plots. It uses regular expression for the extraction
Input: Sequences;
Output: result; string with description of each sequence in FASTA format
*/

// Extract the FASTA description from each sequence
import java.util.regex.Pattern;
import java.util.regex.Matcher;

StringBuffer temp = new StringBuffer();
String information="";
// regular expression to extract only the sequence description
Pattern pattern = Pattern.compile (">(\\w+.*)\\s");
Matcher matcher = pattern.matcher(Sequences);

while(matcher.find()){
	information=matcher.group(1);
	temp.append(information + "\n");
}

// Output sequence description
String result = temp.toString();

Name	Type	Description
Seqs_Fetch	workflow
emma	soaplab	Endpoint http://www.ebi.ac.uk/soaplab/services/alignment_multiple.emma
emma_sprotein_seq	stringconstant	Value Yes
emma_osformat_outseq	stringconstant	Value clustal
database	stringconstant	Value uniprot
ML_reps	stringconstant	Value 50
NJ_reps	stringconstant	Value 100
ClustalW2_ML	workflow
ClustalW2_NJ	workflow
Muscle_ML	workflow
Muscle_NJ	workflow
emma_ML	workflow
emma_NJ	workflow
Tcoffee_ML	workflow
Tcoffee_NJ	workflow
MAFFT_ML	workflow
MAFFT_NJ	workflow
Seqs_Descriptions	beanshell	Script /* Accepts sequences in FASTA format and extracts the information from them for a better understanding of the multiple sequence alignment and trees plots. It uses regular expression for the extraction Input: Sequences; Output: result; string with description of each sequence in FASTA format / // Extract the FASTA description from each sequence import java.util.regex.Pattern; import java.util.regex.Matcher; StringBuffer temp = new StringBuffer(); String information=""; // regular expression to extract only the sequence description Pattern pattern = Pattern.compile (">(\\w+.)\\s"); Matcher matcher = pattern.matcher(Sequences); while(matcher.find()){ information=matcher.group(1); temp.append(information + "\n"); } // Output sequence description String result = temp.toString();
EMBL_EBI_ClustalW2_SOAP	workflow
EBI_MAFFT_SOAP	workflow
EBI_Muscle_SOAP	workflow
EBI_Tcoffee_SOAP	workflow

Name	Inputs	Outputs
Seqs_Descriptions	Sequences	result
Beanshell	inputs	result
Beanshell_2	inputs	result
Beanshell_3	inputs	result
Beanshell_2_2	inputs	result
Beanshell_4	inputs	result
Beanshell_2_3	inputs	result
Beanshell	inputs	result
Beanshell_2	inputs	result
Beanshell_3	inputs	result
Beanshell_2_2	inputs	result
Beanshell_4	inputs	result
Beanshell_2_3	inputs	result
Beanshell_5	inputs	result
Beanshell_2_4	inputs	result
Beanshell	inputs	result
Beanshell_2	inputs	result
Beanshell_3	inputs	result
Beanshell_2_2	inputs	result
Beanshell_4	inputs	result
Beanshell_2_3	inputs	result
Beanshell	inputs	result
Beanshell_2	inputs	result
Beanshell_3	inputs	result
Beanshell_2_2	inputs	result
Beanshell_4	inputs	result
Beanshell_2_3	inputs	result
Beanshell	inputs	result
Beanshell_2	inputs	result
Beanshell_3	inputs	result
Beanshell_2_2	inputs	result
Beanshell_4	inputs	result
Beanshell_2_3	inputs	result
Beanshell	inputs	result
Beanshell_2	inputs	result
Beanshell_3	inputs	result
Beanshell_2_2	inputs	result
Beanshell_4	inputs	result
Beanshell_2_3	inputs	result
Beanshell_5	inputs	result
Beanshell_2_4	inputs	result
Beanshell	inputs	result
Beanshell_2	inputs	result
Beanshell_3	inputs	result
Beanshell_2_2	inputs	result
Beanshell_4	inputs	result
Beanshell_2_3	inputs	result
Beanshell	inputs	result
Beanshell_2	inputs	result
Beanshell_3	inputs	result
Beanshell_2_2	inputs	result
Beanshell_4	inputs	result
Beanshell_2_3	inputs	result
Beanshell_5	inputs	result
Beanshell_2_4	inputs	result
Beanshell	inputs	result
Beanshell_2	inputs	result
Beanshell_3	inputs	result
Beanshell_2_2	inputs	result
Beanshell_4	inputs	result
Beanshell_2_3	inputs	result
Beanshell_5	inputs	result
Beanshell_2_4	inputs	result
Beanshell	inputs	result
Beanshell_2	inputs	result
Beanshell_3	inputs	result
Beanshell_2_2	inputs	result
Beanshell_4	inputs	result
Beanshell_2_3	inputs	result
Beanshell_5	inputs	result
Beanshell_2_4	inputs	result

Name	Description
seqs
o
emmaln
CW_NJ1
CW_NJ2
CW_ML2
CW_ML1
W2_ML2
W2_ML1
W2_NJ2
W2_NJ1
T_ML2
T_ML1
T_NJ1
T_NJ2
Mu_out
Mu_NJ2
Mu_NJ1
Mu_ML2
Mu_ML1
MA_NJ1
MA_NJ2
MA_ML2
MA_ML1
W2-O
W2-aln
W2-t
TC_aln
MAFFT_out
desc
Mu_aln

Source	Sink
seqs_ids	Seqs_Fetch:Sequences_or_IDs
database:value	Seqs_Fetch:DB
emma_sprotein_seq:value	emma:sprotein_sequence
emma_osformat_outseq:value	emma:osformat_outseq
Seqs_Fetch:sequences	emma:sequence_direct_data
ML_reps:value	ClustalW2_ML:r
EMBL_EBI_ClustalW2_SOAP:ClustalW_alignment	ClustalW2_ML:s
NJ_reps:value	ClustalW2_NJ:r
EMBL_EBI_ClustalW2_SOAP:ClustalW_alignment	ClustalW2_NJ:in
ML_reps:value	Muscle_ML:r
EBI_Muscle_SOAP:Muscle_aln	Muscle_ML:s
NJ_reps:value	Muscle_NJ:r
EBI_Muscle_SOAP:Muscle_aln	Muscle_NJ:in
emma:outseq	emma_ML:s
ML_reps:value	emma_ML:r
emma:outseq	emma_NJ:in
NJ_reps:value	emma_NJ:r
ML_reps:value	Tcoffee_ML:r
EBI_Tcoffee_SOAP:Tcoffee_out	Tcoffee_ML:s
NJ_reps:value	Tcoffee_NJ:r
EBI_Tcoffee_SOAP:Tcoffee_out	Tcoffee_NJ:in
ML_reps:value	MAFFT_ML:r
EBI_MAFFT_SOAP:MAFFT_out	MAFFT_ML:s
NJ_reps:value	MAFFT_NJ:r
EBI_MAFFT_SOAP:MAFFT_out	MAFFT_NJ:in
Seqs_Fetch:sequences	Seqs_Descriptions:Sequences
Seqs_Fetch:sequences	EMBL_EBI_ClustalW2_SOAP:Sequences
Seqs_Fetch:sequences	EBI_MAFFT_SOAP:Sequences
Seqs_Fetch:sequences	EBI_Muscle_SOAP:Sequences
emma:outseq	EBI_Tcoffee_SOAP:Sequences
Seqs_Fetch:sequences	seqs
emma:dendoutfile	o
emma:outseq	emmaln
emma_NJ:out	CW_NJ1
emma_NJ:outree	CW_NJ2
emma_ML:out	CW_ML2
emma_ML:outree	CW_ML1
ClustalW2_ML:out	W2_ML2
ClustalW2_ML:outree	W2_ML1
ClustalW2_NJ:out	W2_NJ2
ClustalW2_NJ:outree	W2_NJ1
Tcoffee_ML:out	T_ML2
Tcoffee_ML:outree	T_ML1
Tcoffee_NJ:out	T_NJ1
Tcoffee_NJ:outree	T_NJ2
EBI_Muscle_SOAP:Muscle_out	Mu_out
Muscle_NJ:out	Mu_NJ2
Muscle_NJ:outree	Mu_NJ1
Muscle_ML:out	Mu_ML2
Muscle_ML:outree	Mu_ML1
MAFFT_NJ:out	MA_NJ1
MAFFT_NJ:outree	MA_NJ2
MAFFT_ML:out	MA_ML2
MAFFT_ML:outree	MA_ML1
EMBL_EBI_ClustalW2_SOAP:ClustalW_output	W2-O
EMBL_EBI_ClustalW2_SOAP:ClustalW_alignment	W2-aln
EMBL_EBI_ClustalW2_SOAP:ClustalW_guide_tree	W2-t
EBI_Tcoffee_SOAP:Tcoffee_out	TC_aln
EBI_MAFFT_SOAP:MAFFT_out	MAFFT_out
Seqs_Descriptions:result	desc
EBI_Muscle_SOAP:Muscle_aln	Mu_aln
